Milling and engraving CNC machines allow to realize any of your ideas. All you need is to prepare a model / vector in the program and submit the job to the machine , the rest themselves .

AMAN 3040 4axis 800W - is a professional mini- size machine with working area 300 x 400 mm (30 x 40 cm). Has the most powerful ruler in the spindle and AMAN full four axes : XYZ + A- rotator . The spindle has a water cooling - it provides reliability and long service life.
Difficult to think of the problem , which can not handle this car. The only limitation to the possibilities in front of large and heavy brethren : Stage size and speed of processing , and in the aggregate : functionality, compactness and price - out of competition .
The machine can easily be placed in a small workshop or home. Will apply for relief 3d- treatment ( three-dimensional objects , reliefs, souvenirs, cliche ) , engraving (personalization items , creating labels , jewelry , engraving PCBs ) , all types of cutting (letters and labels , signs , models ) , drilling .
The main types of treatment :

Allows you to handle :

Main areas of application :

To control the machine will need a computer with LPT-port/ USB-port and the operating system Windows XP/windows 7.

Parameter

MAX. X axis travel

300 mm

MAX. Y axis travel

400 mm

MAX. Z axis travel

80 mm

Size

600*700*500  mm

Resolution ratio

0.0125 mm

Table structure

steel alloy plate (with trapezoidal slots

MAX. moving speed

4000 mm/min

Control

3000 mm/min

Main shaft power

800w

Main shaft speed

5000-24000 rpm/min

Tool DIA. range

0.3-3.175 mm,4mm,6mm

Voltage

AC 110V/220V (Optional)

Drive model

Stepper and breakdown

Instruction

G-code

System

Window XP/win 7

 How to set profile for Mach3.

1.Units for motor setup:MM's

2. Motor pulse direction set

3. Motor pulse Speed setup

4. Emergency switch setup

5. Spindle Setup

Packaging & Delivery

Packaging Detail:Standard carton with foam cotton inside.Definitely safe during shipping.Package size: 67*57*51cm

Delivery details:Ship out within 2-3 working days after your payment is confirmed

1.We provide you the friendly English User manual and Mach3 software for free.

2.24 hours technical support by email or calling.
3.Warranty: 1 year free, 2-3 years cost price and free technical support always.
4.Free training to make sure you master the operating of cnc router,  including programming training.
5.Videos of operating the machine are available.

Notes when installation.

1.Assembling and locating the CNC machine on steady desk well.

2.Make sure that your computer has a on-board parallel port output.
3.Installing a CNC control software and Drive such as the MACH 3 or EMC2 on your computer.
4.Connecting the control box with the CNC machine and your computer.
5.Following our manual or guideline to set uo the software.
6.You can enjoy making you dream with using our CNC machine now.

 AMAN MACHINERY CO.LTD

Address :     363/404,xihu east rd., wuxi city, china

Website: www.cncman.net

Worktime : 09:00-18:00 (Beijing time)

Business Phone : 86-510-81802050(Working time)   86--13358108880(Nonworking time)

Fax :  86-510-82443566

Sales manager:Dean

Tele:86+15190304327

Skype:amanmachinery-4

1) This is the first time I use this kind of machine, is it easy to operate?
There is english manual or guide video that show you how to use machine.
If you still have any question, please contact us by e-mail / skype/ phone /trademanager online service.

2) If machine have any problem after I receive it, how can I do ?
Free parts send to you in machine warranty period.
If the part is less than 0.5KG, we pay the postage.
If it exceeds 0.5KG, you need to pay the postage.

3) MOQ ?   1 set machine, mixed order is also welcomed.

4) How can I buy this machine from you? ( Very easy and flexible !)
A. Consult us about this product on line or by e-mail.
B. Negotiate and confirm the final price , shipping , payment methods and other terms.
C. Send you the proforma invoice and confirm your order.
D. Make the payment according to the method put on proforma invoice.
E. We prepare for your order in terms of the proforma invoice after confirming your full payment.
And 100% quality check before shipping.
F. Send your order by air or by sea.
