100mm 200mm 400kg SFU1605 16010 16mm Ballscrew Dual Guide 4sliders Electric Sliding Table Slide Linear Module Platform Router |

100mm 200mm 400kg SFU1605 16010 16mm Ballscrew Dual Guide 4sliders Electric Sliding Table Slide Linear Module Platform Router |

Package Included:

1 X Sliding Table Module

1 X NEMA23 57MM Stepper Motor Mounting bracket

1 X Coupling

Table Module Features :

Model:TH20S-E

Slide material: Aviation aluminum 6061(Surface sandblasting oxidation anti-rust treatment)

Stroke(S):140MM/240MM (Effective Stroke)

Ball screw:SFU1605/SFU1610

Motor: Not included(This slide table can match NEMA23 / NEMA34 / 57MM / 60MM / 80MM / 90MM stepper / servo motor. If you need , please contact us to match)

Horizontal load: 300KG(Max)

Vertical load: 120KG(Max)

Mobile panel size: 150mm X 150mm

Moving speed:300mm/s(Max)

Slide height: 71mm

Floor width: 135mm

Bottom plate thickness: 11mm

Repeat positioning accuracy: 0.02mm

Guide:2XHGR15

Block:4X HGH15

Coupling Motor hole size:8mm

Ballscrew accuracy: C7

Repeat positioning accuracy: 0.02mm

Explanation of screw model:

For Example: SFU1610 , Diameter 16mm, Lead 10mm, The screw rotates once, and the moving panel moves 10mm.

Dimension :

140mm Stroke Slide Table:
240mm Stroke Slide Table:
