Specification

Module Parameter

led dispay screen Size

960mm(L)×960mm(H)

Module Resolution

192(L)×192 (H)

Pitch

5mm

Density

40000 pixels/m²

LED Lamps

SMD2121 (Customizable Nationstar lamp)

Driver IC

Universal chip(Noramlly FM6124)

Module Refresh

2880hz

Mask

Pure Black mask-high contrast screen

Cabinet Parameter

Cabinet Resolution

192(H)×192(W)

Cabinet Size

960mm(H)×960mm(W)

Cabinet Weight

22kg

Driver Mode

Dynamic 1/16 scan , constant current driving

Cabinet Power

≤600w

Cabinet Thickness

≤85mm+5mm

Electricity Parameter

Optical Ratings

Brightness Of  White Balance

≥1300cd/m²

View Angle

140 degree ( horizontal)  140degree(vertical)

View Distance

4m-200m

Gray Scale

65536

Display Color

3-in-1 RGB

Brightness Adjustment

100 levels

Power Supply

Operation Power

AC100-240V 50-60HZ  Switch-able

Maxim Power Consumption

1000 w/m²

Average Power Consumption

500 w/m²

Control System

Correction Scale Level

16bits

Screen Refresh Frequency

960Hz

Gamma Correction

-5.0—5.0

Support Input

HDMI,DVI,VGA,RJ45,USB,Serial Port

Control Distance

Ethernet cable 100m, optical fiber 5km

Support VGA Mode

800×600,1024×768,1280×1024,1600×1200,1920×1080

Color Temperature

5000-9300 adjustable

Brightness Correction

dot by dot, module by module, cabinet by cabinet

Reliability

Temperature

Storage:-35℃-+80℃  ; Operation :-25℃-+45℃

Humidity

Storage:10-70% RH   ; Opreration:10--60% RH

Operating Life

≥100,000 hours

MTBF

≥5000 hours

Continuous Working Time

≥48 hours

Protection Level

IP25

Out of Control Pixel Rate

0.03%

Item include about 1 square meter screen accessories

1),20pcs modules ,

2),3sets 220v-5v40A200w power supply,

3),10pcs power lines ,

4),20pcs flat cables ,

5),1pcs receiving card,

6),one set frame materials(Length less than 1.2meters).

Attention: If you order less than 3 square meters , we will send frame materials , you need assemble by yourself (will send you teaching vidoeo).

Order more than 5 square meters,we will use iron cabinet assble well(charge more 50usd/sqm）

Advantages of use magnets for video wall:

1.Save money (just need materials like modules ,power supply etc ,shipping cost less )

2.Repair easily(just change the bad moudules at front screen ,magnets easy pick down)

3.Beautiful(Screen thickness less than 20cm,look beauiful)

Advantages of use magnets for video wall:

1.Save money (just need materials like modules ,power supply etc ,shipping cost less )

2.Repair easily(just change the bad moudules at front screen ,magnets easy pick down)

3.Beautiful(Screen thickness less than 20cm,look beauiful)

-Last ,debug the display ,then can work normally

In this step ,you need rember that

1).If the display resolution more than 512*1024dots ,you need 2pairs CET5 ,more than 1024*2048dots,need another sending card.

2).If you want to realize picture-in-picture funciton, you need to use the video processor.
