Features:



* 10Bar pressure gauge with mechanical pressure sensor (npt1 / 8 ') for car racing

* Front caliber cover use: red triangles can be used as limit markers, such as speed limits, instead of warning indicators

* To move the position of the red triangle, remove the cover once, adjust its position and reinstall

* Made of high quality material, durable and practical to use

* 100% new and high quality



Specifications:



* Opening size: 60mm

* Working voltage: 10 V-16 V (only for 12 V vehicles)

* Current:

Red line: 200A (when the ignition switch is closed) 0.2mA (when the ignition switch is off)

White: 0.5mA

* Oil pressure range: 200kpa-1000kpa

* Storage temperature range:

Pressure gauge: -30 degrees Celsius (-22 ℉) ~ + 80 degrees Celsius (176 ℉)

Pressure sensor: -30 degrees Celsius (22 ℉) ~ + 140 degrees Celsius (284 ℉)

* Operating temperature range:

Pressure gauge: -30 degrees Celsius (-22 ℉) ~ + 60 degrees Celsius (140 ℉)

Pressure sensor: -30 degrees Celsius (22 ℉) ~ + 120 degrees Celsius (248 ℉)

* Connection instructions:

Red Line: Connect the positive electrode of the power supply (+ 12 V)

Orange line: ING (when the ignition switch is on, connect with 12 V)

White Line: ILM line, backlight (+ 12 V)

Black line: Earth (connected to the negative power source)



How to install:

1 Open the box, take out double-sided tape and put it on the bottom of the stand.

2 Insert the protruding part of the mounting bracket into the instrument cup, and connect the mounting bracket to the instrument cup using the bolts, nuts and washers included in the kit.

3 one to two pieces of double-sided adhesive is connected to the aluminum box and connected to the instrument as a buffer

4. Connect the instrument through the hole in the instrument and connect it to the instrument.

5 Put the meter in the instrument cup to make sure the cable is not caught in the middle.

6 Glue double-sided tape to the back of the mounting bracket, and fold the mounting bracket to meet the position you want to install.



Package content:



1 * pressure gauge

1 * case,

1 * cover

1 * pressure sensor (npt1 / 8 ')

1 * support

1 * bolt and nut

1 * double sided tape

3 * power cables

1 * user manual
