SIM Cards Channel DBL GOIP16 Quad band sms VOIP GSM Gateway GOIP 16 Channel GOIP-16 IMEI change sim bank short antenna

If you are interested in other models VOIP, Pls click below link and buy it on AliExpress.

Description:

The GoIP series gateway is a broadband relay gateway newly developed by DBL Technology. It is a new product for seamless connection between the GSM network and VoIP network. When the mobile phone SIM card is installed in the GoIP, users can register the GSM phone to the VoIP softswitch system. Through the GoIP, users can realize the uplink and downlink calls between the GSM network and the VoIP network. In addition, the GoIP supports the transparent transmission of the caller number from the PSTN to the VoIP.

GoIP is designed to work in conjunction with key phone systems and IP-PBX to provide GSM communications. The extensive compatibility of the GoIP makes it an ideal choice to be deployed in multi-vendor open architecture VoIP networks. GoIP is a great way to provide fast phone service deployment where regular PSTN line may not be readily available. GSM gateway also provides significant savings in usage, infrastructure and maintenance cost compared to conventional PSTN.

The GoIP features embedded SIP and H.323 protocols with flexible setting. The bi-directional password authentication (call authorization) and trust list authentication greatly minimize the risk of charge losses and the flexible routing function can meet special requirements of various call forwarding. In particular, the GoIP gateway supports multi device groups, with flexible setting of large GSM gateway groups with different channel numbers. With its low price, excellent voice quality, and powerful features, the GoIP series gateway is the first choice for system integrators, traffic operators, and softswitch manufacturers.

Basic Function

 LEDs for Power, Ready, Status, WAN, PC, GSM
 Call forward from GSM to VoIP and VoIP to GSM
 Dial in mode or dial out mode only
 Dial Plan
 Password protection for both GSM dial in or dial out

 Retransmit GSM Caller ID to VoIP terminal

Key Features:

 Open Standard VoIP Protocols (ITU H.323 V4 and IETF SIP V2)
Single or Multiple Server Registrations
 Two 10/100 Ethernet for WAN / LAN connections
 GSM module for making GSM calls
 Speech quality ensured by QoS at the Ethernet and IP layers and comprehensive jitter buffer
 VLAN and QoS support
 NAT Transversal and Router functions
 Voice prompts, HTTP Web, Auto Provision support for configuration and updates
 Highly stable embedded Linux operating system in high performance ARM 9 Processor

Enhanced Features
 Dynamic selection of codec
 Advanced jitter buffer
 Automatic traversal of NAT and firewall
 VLAN / Qos
 Router
 Echo cancellation for Speakerphone
 Comfort noise generation (CNG)
 Voice activity detection (VAD)
 Auto provisioning (requires auto provisioning server)
 On line firmware upgrade
 Multi-language support: English and Chinese

Competitive Advantage:

 Remote SIM operation for SIM Card management

 SMPP support for 3rd party development of SMS Applications.

 Free server utilities for remote access and SMS management.

 Telnet mode for sending AT commands to GSM module.

 Compact and light weight design

 Direct customer support

Call Forward
1.Call Origination refers to a call initiated from the PSTN or cell phone network is terminated using VoIP.
2.Call Termination refers to a call initiated as a VoIP call is terminated using PSTN or cell phone network.
3.As shown in the network topology diagram, a VoIP Service Provider is using GoIPs as call origination and termination devices.
    - A call dialed to a GoIP (right hand side) via GSM is first routed via VoIP and then terminated via a VoIP end point or VoIP Service Provider.
    - A VoIP call originated from the left hand side is routed to a GoIP on the right hand side and then is dialed out as a GSM call.

3. IP PBX Call Origination and Termination

1.Instead of FXO gateways, GoIP are as a call termination and origination device for the IP PBX as shown in the diagram above.
2.VoIP endpoints connected to the IP PBX can make calls to cellular/traditional telephone network via the GoIP GSM ports.
3.Outside callers can then call in via the GoIP GSM ports to reach any of the VoIP endpoints that are registered to the IP PBX.
4.GoIP can be configured in a group mode such that all GSM ports can be used by just dialing only one GSM number. Please refer to the Call Center Application for more information.

4. Sending Bulk SMS Service

1.Sending bulk sms text messages is a common technique for telemarketing to reach the target customers.
2.A bulk SMS system can be implemented quickly and easily using GoIPs and our proprietary SMS server. Telemarketers are now have full control on how and when they want to send text messages.
3.In addition, SMS text messages are now used widely in many companies, organizations, schools, clubs as a mean for broadcasting information. They can now build their own SMS system without paying expensive charges to their GSM server provider.
4.This system can also take the advantage of using the same GSM service provider to send sms to the phone subscribers in the same service provider.

5. Call Back

1,Call Back is referring to the telecommunications event that occurs when the originator of a call is immediately called back in a second call as a response.
2,GoIP could be used to achieve this function alone or as an terminal that is integrated in an existing call back server / platform. 3,For standalone operation, GoIP receives a call with caller ID information and then rejects the call immediately without answering the call. GoIP then calls back the caller so that he can dial a phone number to make a call. In this case, GoIP must register to a VoIP Service Provider who can offer terminate the call.
4,In a call back system, GoIP acts as a device to initiate the call back function. Typically, this is done in two ways. The first method is to send an SMS with the callee's phone number to the GoIP. The GoIP then sends both the caller's and callee's phone numbers to the call back server to complete the call back function. The second method is to call the GoIP and the hang up (with the call being answered). GoIP sends the caller's phone number to the call back server and the call back server calls the caller directly so that the caller can then dial a phone number to make a call.
