M8*1.25 110V PFS3508 No mercury Water level switch Tank Pool liquid Sensor Float Promotion new arrival | Инструменты

M8*1.25 110V PFS3508 No mercury Water level switch Tank Pool liquid Sensor Float Promotion new arrival | Инструменты

Contact form:A(Normally Open)
Max Contact Resistance:100m

Max Contact Rating:10W/50W

Place of Origin: Zhejiang, China (Mainland)

Brand Name: ELE

Model Number: -PFS3508

Contact Capacity: AC220V/1A;DC24V/0.5A

Working Pressure: 0.5MPa

Housing Materia: PP

Float Materia: PP

Wire Length: 50010mm

Working Temperature: -10~85

Ambient temperature range: -10~+60

Contact form: A(Normally Open)

Max Contact Resistance: 100m

Max Contact Rating: 10W/50W

-PFS3508 Plastic Float Switches Introduction:

A float switch is a device used to detect the level of liquid within a tank. The switch may be used in a pump, an indicator, an alarm, or other devices.
Float switches range from small to large and may be as simple as a mercury switch inside a hinged float or as complex as a series of optical or conductance sensors producing discrete outputs as the liquid reaches many different levels within the tank. Perhaps the most common type of float switch is simply a float raising a rod that actuates a microswitch.

PFS3508 Plastic Level Switches Specification:

Magneti reed type

1A1

2A1

Max Contact Rating

10W

50W

Max Switching Voltage

100V DC

220V DC

Max Switching Current

0.5A

1.5A

Max Breakdown Voltage

220V DC

300V DC

Max Carry Voltage

1.0A

3.0A

Max Contact Resistance

100m

100m

Ambient temperature range

PP material

-10~+60C

Stainless steel material

-30~+125C

Liquid temperature range

PP material

-10~+85C

Stainless steel material

-30~+125C

-PFS3508 Float switches Applications:

Drinking fountains, water heaters, solar energy, air conditioners, humidifiers, water, bathroom equipment, vending machines, tanks, chemical liquid level control, automotive, industrial equipment, agricultural equipment, household appliances widespread application prospect.

How to choose suitable float switch for different liquid?
