30A 48V Solar Charge Controller Digital LCD Display Solar Panel Light Timer Control for Off Grid System Solar Voltage Regulator

    Features ★  Image of LCD graphic symbol  ★  Simple button operation
★  Automatic Identification System Voltage level
★  Intelligent PWM charge mode
★  Automatic Temperature Compensation
★  Adjustable charge-discharge control parameters
★  Settable Operating mode of Load
★  Overload, Short Circuit Protection
★  Remote monitoring and control function (custom)
★  Battery reverse-discharge protection
★  Battery Low Voltage Disconnection (LVD)
★  Battery reverse connection protection
★  Accumulated function of charge and discharge Ampere hours       Specifications

Model

CM2024Z

CM3024Z

CM2048Z

CM3048Z

Rated Current

20A

30A

20A

30A

Rated Voltage

12V/24V

48V

Open Circuit Voltage of solar panel

<=50V

<=100V

Low Voltage Disconnection(LVD)

10.7V/21.4V

42.8V

Float Voltage

13.8V/27.6V

55.2V

Low Voltage Reconnection(LVR)

12.5V/25.0V

50.0V

No load loss

<=30mA

Loop Voltage Drop

<=170mV

Charging Mode

PWM mode

Temperature Compensation

-4mV/Cell/'C

Installation cable area.

<=7#AWG (16mm2)

Operating Temperature

-10'C--60'C

Storage temperature

-30'C--70'C

Humidity requirements

<=90%,no condensation

Size

90 mmx188 mmx48 mm

Mounting hole spacing

60 mmx178 mm --dia5

weight

360g



Package including 1PCS  30A solar controller 1 PCS  User  manual 1 PCS Temp sensor
