Seetec PF173-9CT 17.3 Inch 1920x1080 Open Frame Monitor 17.3" Projected Capacitive 10-Point Touch LCD Industrial on. -> Монитор Seetec PF173-9CT 17.3 дюйма, 1920x1080 пикселей, с открытой рамкой, проекционная ёмкостная 10-точечная сенсорная ЖК-пан

Seetec PF173-9CT 17.3 Inch 1920x1080 Open Frame Monitor 17.3" Projected Capacitive 10-Point Touch LCD Industrial on. -> Монитор дюйма пикселей с открытой рамкой проекционная ёмкостная 10-точечная сенсорная ЖК-пан

SEETEC industrial capacitive touchscreen monitor with rugged metal frame, flat LCD panel design, compact structure, durable, with impact resistance, anti-interference, heat dissipation and other advantages, meeting the embedded or external installation needs simultaneously. Its several top features along with superior engineering make these open frame monitors as ideal solutions for high quality displays.
The capacitive touch screen is equipped with 10 point touch, fast, accurate and smooth touch experience. It is widely used in industrial display, medical display, commercial LCD display, financial equipment, self-service terminal.

Model

 PF173-9CT

 Touch Screen

 Capacitive Touch

 Touch Interface

 USB

 Multi-Touch Support

 10 Points

Screen Size

17.3" IPS

 Display Colors

 16.7M colors (RGB 8-bit)

 Resolution

 1920×1080 pixels

 Dot Pitch

 0.1989(H)×0.1989(V) mm

 Aspect Ratio

 16:9

 Brightness

 400cd/m⊃2;

 Contrast Ratio

 600:1

 Backlight

 LED

 Viewing Angle

 80°/80°(L/R) 60°/80°(U/D)

HDMI, DVI, VGA, YPbPr, Video, Audio in, Audio out, USB for touch

VESA 4-hole 100mm mounting / Rack Mount

 Input Voltage

 DC12V

 Power Consumption

 ≤18W

 Working Temperature

 -10℃～50℃

 Storage Temperature

 -20℃～60℃

 Unit Size

 408.6Lx246.8Hx38.1D (mm)

 Unit Weight

 3.3kg

Dimensions (Unit: mm)

Industrial Display Solution
1920x1080 see every pixel in detail
Industrial high-definition LCD screen, 1920x1080 Full HD resolution, the image is clear and natural; at the same time with low power consumption, long-time operation ability, can adapt to almost all of harsh environment.

10-point Capacitive Touchscreen
Faster, more accurate, more stable touch experience
SEETEC using the 10 point projected capacitive touch technology, the glass surface smooth touch, give you an impeccable fast touch experience.

Accurate Touch Screen

Use ultra-sensitive touch screen
Only need one time calibration to improves touch accuracy, no dead end touch, no break, drift, when you write on it, you can hardly feel any delay or deviation.

Compatible System

Support Windows 7 / Windows 8 / Windows 10 / Android operating systems, greatly enhanced the versatility of the terminal, for industrial, medical, hotel, and other industry display, meet the interactive touch demand.

Flat Panel
Smoother and faster
Interactive touch display, flat slim design, coupled with circular streamline shape, no sharp edges, ergonomic design, simple and elegant.

Rich Interfaces
Meet the industrial display application needs
Not only equipped with USB (for touch), DC12V power, HDMI, VGA, YPbPr, VIDEO, AUDIO input interface, also equipped with 3.5mm stereo headphone output and speakers.

Flexible Installation
Support embedded, VESA wall-mounted and other installation methods, to facilitate the flexible display application, ideal solution for kiosk integrator and store retail. (The rack mount brackets can meet your embedded installation requirements, the standard VESA 100x100mm screw hole can support wall-mounted installation.)

Industrial Grade Rugged Design
All metal shell, compact, durable, designed for all kinds of industrial needs, impact resistance, anti-interference, heat fast, to adapt to a variety of harsh working environment. Metal narrow frame design, rounded corners, exquisite design.

Application Solution
Widely used in industrial display, industrial control, medical equipment, military field, fire equipment, car display, video conferencing systems, entertainment and leisure, business self-help, financial institutions, query equipment and other fields, and also applies to harsh environments.

Standard Accessories:
1× Power Adapter
1× VGA Cable
1× USB Touch Cable
1× Manual
