Product List:

Control card*1

1M network cable*1

MPG*1

Hook*1

CD*1

DC75W24V

Introduction:

NVEMv2.1 is a 3-axis-6-axis motion controller;
The control cycle of each position is 2 milliseconds, and the control accuracy is high. The highest single-axis output pulse is 200KHz, the pulse width is adjustable, and it supports common stepper motors and servo motors.
NVEMv2.1 supports mach3 control, perfectly supports standard electronic handwheels, and communicates with the computer using Ethernet, which can be directly connected to a network cable or transited by a router, and is not limited by the length of the network cable.
NVEMv1.1 CNC system adopts ARM design architecture, and ARM completes parts including communication, code analysis, underlying algorithm and control pulse generation. Reasonable design, reliable control and convenient operation.

Performance parameters:

S Support Ethernet;

S 12 ports photoelectric isolated input interface for ordinary digital data；

S 10 ports photoelectric isolated output interface for ordinary digital data；

S 1 port 0-10V spindle speed analog output interface(can change to PWM output)；

S can support 3-6 axis stepper systems,200KHz pulse output for every axis；

S ARM motion control chip；

S main device is 12V-32VDC power supply input,current should higher than 0.5A；

S Compatible with MPG input,support the digital display MPG from our company。

Appearance and size:

NVUMV2.1 motion controller is with the sealed shell structure,there are 4pcs setting holes

at the bottom.We can fix 4pcs 4mm diameter holes at the cabinet,and install the controller into

the cabinet.The controller appearance as the Figure 1-1 and Figure 1-2 show:

The products overall size is 137.1mm*80.8mm*27.8mm；

The bottom install size is 101.4mm*39.5mm。

Power scheme:

Wiring definition:

The controller connection includes:

1. Power interface,

2. Ethernet connection interface,

3.MPG interface,

4. Step/servo control output interface,

5. Spindle control output interface,

6.Estop and limit switch and tool setting input interface

and so on.

 Now we descript them in details as below.
