HD360 ARC аудио экстрактор HDCP CEC оптический TOSLINK SPDIF 3,5 мм RCA конвертер 4K x 2K 3D HDMI-совместимый аудио сплиттер адаптер.

HD360 ARC аудио экстрактор HDCP CEC оптический TOSLINK SPDIF 3 5 мм RCA конвертер 4K x 2K 3D HDMI-совместимый сплиттер адаптер.

This hdmi audio converter can extract the audio signal embedded in HDMI sources and convert it to 3.5 mm analog audio output and SPDIF output at the same time. The SPDIF out supports both 2 CH audio and 5.1 CH audio including Dolby Digital 5.1 CH and DTS 5.1 CH. The HDMI out supports 7.1 CH audio including Dolby Digital 7.1 CH and DTS 7.1 CH.Ultra long distance transmission up to 40 meters (input + output), no signal loss. 99% do not need external power supply, plug and play, more convenient, more environmentally friendly.

Features:
• Input ports: 1 x HDMI, 1 x Micro USB power port, 3 x EDID Audio (pass, 2 CH, 5.1 CH)
• Output ports(HD360): 1 x HDMI, 1 x SPDIF (optical), 1 x 3.5 mm jack.
• Output ports(HD365 with ARC): 1 x SPDIF (optical), 1 x 3.5 mm jack.
• HDMI resolutions: 4K x 2K, 24/50/60/1080P/1080i/720p/576p/576i/480p/480i
• Supported color formats: 24 bit/deep color 30 bit, 36 bit
• Max bandwidth: 225 MHz
• Max baud rate: 6.75 Gbps
• Max working current: 190 mA
• Audio and video can be converted from the HDMI output
•Pass: support 7.1 channel output, device read the HDMI OUT audio signal directly
•2CH: 2.1 stereo channel output
•5.1CH: optical fiber 5.1 digital surround audio (DTS, Dolby, AC3) and other outputs;Support 24bit / 192Khz audio sampling rate

Packaging :
1 X HDMI audio converter
1 X Optical audio Cable
1 X 3.5mm to RAC audio Cable
1 x micro USB cable

PS:
HD360 does not support ARC function
HD365 supports ARC function without HDMI output

Warnings:
• The product not change the audio format, just provide a signal for the device connected to HDMI in to automatically identify what format audio output by this channel.
• Device does not support Dolby Digital Plus audio. It supports DTS audio and Dolby Digital audio.
• For devices with low power HDMI ports or over 15m, a 5V/1A phone adapter can be used to power the device.
• Device does not support copyright protected content.
