"20A high-power PWM DC motor speed controller brush reducer slow start current limit 12V36V48 " | Строительство и ремонт

"20A high-power PWM DC motor speed controller brush reducer slow start current limit 12V36V48 " | Строительство и ремонт

Features：

Soft start! Stall protection! Motor characteristics The instantaneous current is large and the locked-rotor current is infinite Soft start can solve the damage caused by instantaneous high current to the governor Locked-rotor protection (current limiting system) can limit the large current generated by the motor's locked-rotor

Note:

The locked rotor protection is not a power failure but a current limit value of 20A

Product parameter：

Product Name: Three Provinces 20AL Input voltage: DC 10-60V (the specific voltage must be equal to the rated voltage of the motor) Output voltage: linear under load Speed adjustment range: 0-100% Speed regulation method: linear potentiometer 270 degrees (with switch) Support motor: DC brushed Output current: 20A (current limit value 20A) Power conversion: equal to voltage * current 12*20A=240W. Body size: 96mm*61mm*34mm Panel opening: 92mm*56mm Product Net Weight: 106g

note:

Input must be positive and negative The input voltage must be equal to the rated voltage of the motor (within 10-60V) Can not input 220V household electricity input 220V directly burned
